𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀

CPU
- Intel® Socket LGA1700 for 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*

Chipset
- Intel® Z790 Chipset

Memory
- 4 x DIMM, Max. 192GB, DDR5
- Dual Channel Memory Architecture
- Supports Intel® Extreme Memory Profile (XMP)

Graphics
- 1 x HDMI® port**
- 2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort 1.4 and Thunderbolt™

Expansion Slots
- 2 x PCIe 5.0 x16 slots
- 1 x PCIe 4.0 x16 slot

Storage
Intel® 13th & 12th Gen Processors*
- M.2_1 slot (Key M), type 2242/2260/2280/22110
- Hyper M.2_1 slot (Key M) via ROG Hyper M.2 card, type 2242/2260/2280/22110
Intel® Z790 Chipset**
- M.2_2 slot (Key M), type 2242/2260/2280
- M.2_3 slot (Key M), type 2242/2260/2280
- Hyper M.2_1 slot (Key M) via ROG Hyper M.2 card, type 2242/2260/2280/22110
- Hyper M.2_2 slot (Key M) via ROG Hyper M.2 card, type 2242/2260/2280/22110
- 6 x SATA 6Gb/s ports****

Ethernet
- 1 x Intel® 2.5Gb Ethernet
- ASUS LANGuard

Wireless & Bluetooth
- Wi-Fi 6E
- 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5/6GHz frequency band*
- Bluetooth® v5.3**

Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
- Impedance sense for front and rear headphone outputs
- Support up to 32-Bit/ 384 kHz playback on front panel

Operating System
- Windows® 11, Windows® 10 64-bit

Form Factor
- ATX Form Factor
- 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
