Description
Maximize viewing flexibility with the PLB-CE1544L full-motion TV ceiling mount, providing exceptional versatility and universal compatibility. Easy assembly, heavy-duty construction, and flexible adjustments ensure an excellent user experience. Its tiltable ceiling plate is designed to adapt to flat and pitched roofs. Ideal for supermarkets, airports, restaurants, conferences, and more.

FEATURES
●Adjustable Ceiling Plate: for mounting in flat or sloping ceiling
●360° Rotation Around the Pole: provides optimal viewing
●Telescoping Height Adjustment: for the optimal viewing height
●Free-Tilting Design: makes easy forward or backward adjustment for better viewing and reduced glare
●Leveling adjustments: allow TV to be perfectly positioned after hanging
●Cable Management: keeps everything organized

SPECIFICATIONS
Product Category: TV Ceiling Mount
Rank: Standard
Material: Steel
Metal Sheet Thickness: Bracket Arm THK=1.5mm cold-rolled sheet,VESA Panel THK=1.8mm cold-rolled sheet,Wall Plate THK=2.5mm pickling sheet (Bracket Arm THK=0.059" cold-rolled sheet,VESA Panel THK=0.071" cold-rolled sheet,Wall Plate THK=0.098" pickling sheet)
Pipe Size: φ40x1.2mm Round Steel Tube,φ48x1.5mm Round Steel Tube (φ1.6"x0.047" Round Steel Tube,φ1.9"x0.059" Round Steel Tube)
Surface Finish: Powder Coating
Color: Fine Texture Black
Dimensions: 1905x489x154mm (75"x19.3"x6.1")
Fit Screen Size: 32"-75"
Fit Curved TV: Yes
Mounting Hole Pattern: VESA & Universal
VESA Compatible: 200x200,300x200,400x200,300x300,400x300,400x400
Max. Mounting Hole: 410x402
Weight Capacity: 60kg (132lbs)
Strength Tested: 4 Times Approved
Profile: 1090~1690mm (42.9"~66.5")
Tilt Range: 0°～-25°
Swivel Range: +180°~-180°
Screen Level: +3°~-3°
Screen Freely Tilting: Yes
