Technical Spec
Motherboards : Mini-ITX / Micro-ATX / ATX
Materials : ABS+SPCC+Tempered Glass
Product Dimensions : 424.6mm×215mm×494.6mm(L×W×H)
Carton Dimensions : 540mm*283mm*495mm
Net Weight : 8.33KG
Gross weight : 10.34KG
5.25" Drive Bays : 0
3.5" Drive Bays : 2
2.5" Drive Bays : 2
I/O Panel : SB3.0×2、Audio×1、Mic×1
Expansion Slots : 7+2 Slots
Cooling Fans Compatibility : Pre-installed: Rear: 1×120mm DC fan; Optional: Front: 120mm×3/140mm×2， Top: 120mm×3/140mm×2
Power Supply Type : ATX PS2 (Length less than 160mm)
CPU Cooler Height Limit : 165mm
Liquid Cooler Compatibility : Front: 120/140/240/280/360; Rear: 120
VGA Length Limit : 330mm
Cable Management : 23mm clearance
