MODEL : ELC-LMT240-ARGB
CPU SOCKET : Intel® LGA 1200/2066/2011-3/2011/1366/1156/1155/1151/1150
AMD® AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
TDP (W) : 330W
COLD PLATE MATERIAL : Copper Base
RADIATOR MATERIAL : Aluminum
RADIATOR DIMENSION : 274 x 120 x 27 mm
PUMP BEARING : Ceramic Bearing
PUMP MTBF : 50,000 hrs
PUMP RATED VOLTAGE (V) : 12V
PUMP RATED CURRENT (A) : 0.4 A
[ or 0.53A if not connected to 3 pin ARGB connector (5V/D/G) ]
PUMP RATED CURRENT - RGB LED (A) : 0.18A (5V)
FAN DIMENSION (MM) : 120 x 120 x 25 mm
FAN SPEED (RPM) : 500~1600 rpm
FAN RATED VOLTAGE (V) : 12V
FAN AIR FLOW (CFM) : 22.5~72.1 CFM
FAN STATIC PRESSURE (MM-H2O) : 0.2~1.98 mm-H2O
FAN RATED CURRENT (A) : 0.17A
FAN RATED CURRENT RGB LED (A) : 0.36 A (5V)
FAN MAXIMUM NOISE (DBA) : 14~27 dBA
FAN MTTF (HOURS) : 50,000 hrs
FAN CONNECTOR : 4 pin PWM connector
3 pin ARGB connector (5V/D/G)
FAN SCREW : 6#32
THERMAL GREASE : Dow Corning® TC-5121C
