Solid and sturdy, the Anode Bronze is a strong contender for any discerning builder. Semi-modular cables offer easier installation and less clutter, while the 5-year warranty ensures value over time.

• 80 PLUS Bronze efficiency ensures high reliability
• Semi-modular cables for easier installation and less clutter
• Efficient DC-DC design and modern ATX 2.52 standard offer tight timing limits

Specifications
80PLUS certification Bronze
PSU form factor ATX
Modular cables Semi
Fan type 120mm
Maximum operating temperature (full load) 40°C
Capacitors Main: Japanese Bulk: Taiwanese
Life expectancy 100,000 h
Cable type Fixed cables: Sleeved Modular: Flat ribbon
Input voltage 100-240 V
Number of 12V rails Single rail
Protection features OVP,UVP,OPP,SCP, OCP (3.3V + 5V) OCP 12V, OTP
Standby efficiency 2016 Lot 6 (0.5W 55mA)
Approvals & certifications CB, TUV, cTUVus, FCC, CE, RCM, CCC, BSMI, UKCA, EAC
Warranty 5-year

Connectors
Connectors in PSU shroud
Fixed: 12V 20+4 pin, CPU 4+4 Modular: 4x 6-pin, 3x 8-pin
Cable configuration PCIe
(6+2 pin x2) (520 + 100mm) (6+2 pin x2) (520 + 100mm)
Cable configuration SATA
(SATA x2) (650 + 150mm) (SATA x3) (400 + 150 + 150mm) (SATA x3) (400 + 150 + 150mm)
Cable configuration peripheral
(MOLEX x2) (400 + 150mm)

DC Output
3.3V 22.00A
5V 22.00A
12V 62.50A
-12V 0.30A
+5Vsb 3.00A
Total Power 750W

Other
Package contents
Anode Bronze Power Supply, Modular cables, Screw pack and zip ties, AC power cord (localized), User Manual Unit dimensions (LxWxH) 140 x 150 x 86 mm
Net weight (unit only) 2,1 kg
Package dimensions (LxWxH) 285 x 212 x 110 mm
Package weight (w/o AC cable) 2,4 kg
EAN 7340172703785
UPC 843276103781
JAN 4537694294959
Product code FD-P-AA1B-750
