Motherboard GIGABYTE Z890 AORUS ELITE WIFI7 GAMING

CPU : LGA1851 socket: Support for Intel Core Ultra Processors
Chipset : Intel Z890 Express Chipset

Memory :
Support for DDR5 up to 9200(O.C)
4 x DDR5 DIMM sockets supporting up to 256 GB
Dual channel memory architecture
Support for Extreme Memory Profile (XMP) memory modules

Onboard Graphics :
1 x Intel Thunderbolt 4 connector (USB4 USB Type-C port), supporting DisplayPort and Thunderbolt video outputs.
1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz

Audio :
Realtek ALC1220 CODEC
High Definition Audio
2/4/5.1/7.1-channel

LAN : Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless Communication module : Wi-Fi 7 & BLUETOOTH 5.4

Expansion Slots :
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
- 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2)

Storage Interface :
1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU)
1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU)
Chipset:
1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB)
4 x SATA 6Gb/s connectors

Back Panel Connectors :
1 x Intel Thunderbolt 4 connectors (USB Type-C ports)
2 x USB 3.2 Gen 2 Type-A ports (red)
3 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
2 x antenna connectors (2T2R)
1 x DisplayPort (Note)
1 x RJ-45 port
1 x optical S/PDIF Out connector
2 x audio jacks

Form Factor : ATX Form Factor; 30.5cm x 24.4cm

Garansi Resmi 3 Tahun
