CPU
- Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset
- Intel Z690

Memory
2 x DIMM, Max 64GB. DDR5 Up to 6800+ MHz

Graphics
- 1x DisplayPort 1.4 port, supporting a maximum resolution of 4K 60Hz 1/2
- 1x HDMI 2.1 with HDR port, supporting a maximum resolution of 4K 60Hz 1/2

Thunderbolt
- Intel® JHL8540 Thunderbolt™ 4 Controller
- 2x Thunderbolt™ 4 (USB-C) ports on the back panel

Expansion Slots
- 1 x PCIe 5.0 x16 slot(s)***

Storage
- 4x SATA 6Gb/s ports (From Z690 chipset)
- 3x M.2 slots (Key M)
# M2_1 slot (From CPU), Supports up to PCIe 4.0 x4, Supports 2280 storage devices
# M2_2 slot (From Z690 chipset), M2_2 supports up to PCIe 3.0 x4, Supports up to SATA 6Gb/s, Supports 2280 storage devices
# M2_3 slot (From Z690 chipset), M2_3 supports up to PCIe 4.0 x4, Supports 2280 storage devices
# M2_2~3 slots support Intel® Optane™ Memory
- Supports Intel® Smart Response Technology for Intel Core™ processors

Ethernet
- 1x Intel® I225V 2.5Gbps LAN controller

Wireless & Bluetooth
- Intel®Wi-Fi 6E
- The Wireless module is pre-installed in the M.2 (Key-E) slot
- Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz 1(160MHz) up to 2.4Gbps
- Supports 802.11 a/ b/ g/ n/ ac/ ax
- Supports Bluetooth® 5.22, FIPS, FISMA

Form Factor
- Mini ITX
- 17cm x 17cm
