GPU
Radeon™ RX 5500 Graphics
2nd Gen 7nm GPU
RDNA Architecture

Engine Clock
Boost Clock: Up to 1845MHz
Game Clock: Up to 1737 MHz
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors : 1408
Memory Size/Bus : 8GB/128 bit GDDR6
Memory Clock : 14.4 Gbps Effective
Displays : Maximum 4 Displays
Resolution :
HDMI™: 4096×2160@60Hz
DisplayPort1.4: 5120×2880@60Hz

Interface
PCI-Express 4.0

Output :
2x HDMI
2x DisplayPort
BIOS Support : Dual UEFI

API :
Vulkan®
OpenGL® 4.6
OpenCL 2.0
DirectX® 12
Shader Model 6.4

Game Index : Extreme 1080P

Cooling :
Dual-X Cooling
Dual Fan
Two-Ball Bearing

Form Factor :
2.2 slot, ATX
Dimension: 257 x 132.8 x 44.2 (mm)

Power Consumption : 135W

OS :
Linux®, Windows® 10, Windows® 7
64bit operating system required

System Requirement :
Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply).
1 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 4GB of system memory. 8GB recommended.
