GPU : Radeon™ RX 6800 Graphics
7nm GPU
RDNA 2 Architecture
Engine Clock :
Boost Clock: Up to 2190 MHz
Game Clock: Up to 1980 MHz
Game Clock is the expected GPU clock when running typical gaming applications,
set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors : 3840
Infinity Cache : 128MB
Ray Accelerators : 60
Memory Size/Bus : 16GB GDDR6
Memory Clock : 16 Gbps Effective
Displays : Maximum 4 Displays
Resolution : HDMI™: 7680×4320
DisplayPort1.4: 7680×4320
Output : 1x HDMI
3x DisplayPort


BIOS Support : Dual UEFI
Game Index : 4K
Cooling : 3 Fans
Form Factor : 2.7 slot, ATX
Dimension: 310.5(L)X 134.2(W)X 55.2 (H)mm
Power Consumption : 290W
OS : Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required
System Requirement : Minimum 750 Watt Power Supply
2 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended.
