SPECIFICATIONS:
CONTROLLER : PHISON E19T
FLASH MEMORY : 3D NAND
FORM FACTOR : M.2 2280
INTERFACE : PCIe Gen4x4, NVMe 1.4
COMPATIBILITY : PCIe Gen4 / Gen3 / Gen2 / Gen1
DIMENSIONS : 80.00mm (L) x 22.00mm (W) x 2.15mm (H)
SEQUENTIAL READ UP TO (MB/S) : 3600
SEQUENTIAL WRITE UP TO (MB/S) : 3000
RANDOM READ 4KB UP TO (IOPS) : 420,000
RANDOM WRITE 4KB UP TO (IOPS) : 550,000
MAXIMUM OPERATING POWER (W) : 4.0
MEAN TIME BETWEEN FAILURE (MTBF) : Up to 1,500,000 Hours
LIMITED WARRANTY : 5 Years, or the coverage for the maximum TBW as stated, whichever comes first.
ADVANCED FEATURES :
TRIM (Performance Optimization, OS support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
TCG Pyrite (Encryption, Data Security)
