Network & Ports
• PoE Ports: 8 x 10/100 Mbps RJ45 (Ports 1–8)
• Uplink Ports: 2 x 10/100/1000 Mbps (Gigabit) RJ45 (Ports 9–10)
• Standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, 802.3u, 802.3x, 802.3ab
• Transmission Distance: * Normal Mode: Up to 100 meters
- AI Extend Mode: Up to 250 meters (at 10 Mbps)

Power Specifications
• Total PoE Budget: 96W
• Max Power per Port: 30W (IEEE 802.3at)
• PoE Pin Assignment: 1/2 (+), 3/6 (-)
• Power Supply: Built-in power module

Performance & Hardware
• Switching Capacity: 5.6 Gbps (non-blocking)
• Packet Forwarding Rate: 4.17 Mpps
• MAC Address Table: 2K
• Cooling: Fanless design (Silent operation)
• Lightning Protection: Up to 6KV (common mode)
• Dimensions: 184mm x 94mm x 27mm

AI Intelligent Features
This switch includes a manual toggle switch to enable four "AI" smart modes:
1. AI VLAN: Isolates ports 1–8 from each other to suppress network storms and improve security.
2. AI Extend: Increases the transmission distance to 250 meters for long-range IP camera deployments (lowers speed to 10Mbps).
3. AI PoE (Watchdog): Automatically detects a non-responsive IP camera and restarts the specific PoE port to recover the device.
4. AI QoS: Prioritizes video data packets to ensure smooth playback even when the network is congested.
